- Brand Name: Minithink
- Compatible Brand/Model: Nintendo
- Nintendo Model: NINTENDO SWITCH
- Certification: None
- Origin: CN(Origin)
- Package: Yes
- Model Number: PG-9139
- Interface Type: bluetooth
- Color: Black
1. Applicable equipment: When using N-Switch host/tablet/PC (Win 7/8/10 system)/Bluetooth connection on smartphone, use it during game operation;
2. The structure is ergonomic and comfortable to the touch;
3. Support 3D interchangeable function, replace 3D and function key position according to user’s own experience, get a better experience;
4. Back-key L1, L2, R1, R2 custom programming:
5. Product cool color LED backlight
Working voltage: DC3.7V
Working current: <35mA
For continuous use: more than 15 hours
Sleep current: <40uA
Charging voltage / current: DC5V / 500mA
Bluetooth 4.0, transmission distance: ≤8M
Battery capacity: 650mAh
Standby time: 30 days at full power
Controller operation instructions
1. Pairing connection: Press the small button on the right side of the back for 1 second to enter the Bluetooth pairing state. The LED 1-4 indicator light flashes in the marquee mode, and the middle color LED light flashes in 7 colors. If the pairing is successful within 2 minutes, The handle goes to sleep.
2. Pairing success: After the Bluetooth pairing is successful, the LED1-4 indicator light is always on according to the default channel assigned by the host, and the middle color light enters the 7-color cycle and flashes slowly (the interval between each color is 3 seconds).
3. Pairing back connection: Press the HOME button for 1 second to enter the Bluetooth connection state, the LED1-4 indicator light flashes in the marquee mode, and the middle color LED light flashes in 7 colors.
1. Connection method: directly connect the computer and the handle with the data cable; the LEDs of the XINPUT mode LEDs 1, 2, and 3 are always on.
In the DINPUT mode, the LEDs 1 and 2 are always on; in the two modes, the central lantern enters the 7-color slow flash (3 seconds between each color) state.
2. Press and hold the ‘-‘ (SELECT) and ‘+’ (START) buttons together for 3 seconds to switch modes between XINPUT mode and DINPUT mode.
Programmable button function:
1. The programming function can realize any one of A, B, X, Y, L, ZL, R, ZR.
2. Set the programming button: first press and hold the ‘+’ (START) button, and then press the button that needs to be programmed on the back, then the white light flashes 2 times and then stays on. At this time, release the button and press any function key (A, B, X, Y, L, ZL, R, ZR) that needs to be copied again, that is, the setting is completed, and the programming mode is automatically exited after the setting is completed.
3. Cancel the programming key: first press and hold the ‘+’ (START) key, and then press the programming key that needs to be canceled to complete the cancel programming setting.
1. The action button includes (A/B/X/Y/L/ZL/R/ZR) eight buttons, all of which can be used with the TURBO function.
2. The TURBO switch can be set manually by any action button.
3. Setting method: Press the action button first, then press the TURBO button at the same time, the TURBO function is turned on; press the action button first, then press the TURBO button, the TURBO function is turned off.
4. When the handle is turned off, power off, hibernation, when the handle is restarted, the Turbo function is automatically cleared before setting. If the Turbo function is enabled, it must be reset.
Handle Charge/Sleep/Wake-up/Shutdown/RGB Light Settings:
Charging: When the LED is turned off, the LEDs 1, 2, 3, and 4 are flashing at the same time. The middle color is solid green, the LEDs 1, 2, 3, and 4 are off. The middle color is steady red.
Charging in the connected state, the LED light flashes slowly in the current mode, the flashing light keeps flashing in the current mode, and the current mode indicator is always on.
Low battery: In any mode, the low battery alarm is flashing LED4, and the flashing mode keeps the current mode flashing.
What in the box
1*Cross disc key
